Servo System M6-L Direct Drive Servo System
M6-L Direct Drive Servo System
M6-L, direct drive servo, is designed by Megmeet to drive DDR and DDL. The direct drive servo system, which runs stably with fast response and high accuracy, is equipped with advanced functions including but not limited to online inertia identification, gain auto-tuning, vibration suppression and quadrant compensation. Besides, the Megmeet host controller further facilitates the use of M6-L servo system in the market of mechanical equipment to achieve high precision, high stability and high efficiency.
Download
Features
High Response
1. Increase from 1.0 kHz to 2.6 kHz
2. High refresh frequency of current loop and speed loop
3. Fast response to commands
4. High rigidity
High Overload
3 times overload
High Bandwidth
1. Input/Out frequency up to 4 Mpps
2. Differential input
3. AB orthogonal, direction+pulse, CW/CCW
Various Motors
1. DDR motors
2. DDL motors
Integrated Encoder Interface
1. Incremental encoder
2. Sin/Cos encoder
3. Absolute encoder
4. HALL signal
Applications
Robots and other logistics vehicles for goods transportation and storage
Download
M6-L Direct Drive Servo System Brochure
1.5M
2025-03-24
M6-L Series Servo System User Manual
7.1M
2025-09-28
Servo Host Computer Ms Software (M5,DM5,M6,HM6,M6-L S6, MV600J6/J6B,MV810J)
78.8M
2024-12-24
