Industrial IOT Solutions

Introduction

Under the wave of intelligent manufacturing in Industry 4.0, equipment manufacturers and production plants need a complete set of remote information systems to improve production and operation and maintenance efficiency.

The Internet solution of industrial equipment provided by Megmeet to customers, through the latest industrial interconnection technology, connect your device to the Megmeet cloud platform, realize the remote interconnection of a large number of devices, and provide you with efficient and stable data transmission , Accurate and timely data analysis, and rich and diverse use methods to help you enter the era of industrial Internet cloud.

Introduction to Megmeet Industrial Internet of Things

The schematic diagram of the Industrial Internet of Things solution is shown in the following figure, which is divided from left to right: data acquisition layer, MGMI cloud platform, data center and management system.

1、Data collection

Mlink connects with on-site PLCs, meters, frequency converters and other equipment, and transmits equipment data to the megameter cloud platform through broadband, 2G, 3G, 4G and other Internet access methods.

2、MacMetter Cloud Platform

Mlink is connected to the site to realize the connection management, data collection, storage and transmission of a large number of remote devices. It is a bridge between the field device and the user client.

2.1 Megmeet Cloud MServer

MServer is used to remotely connect a large number of on-site Mlink to realize the functions of connection management, data collection, storage and forwarding of a large number of remote devices.

2.2 Cloud configuration

The remote cloud platform is a web configuration software developed by Megmeet in response to the development needs of the industrial Internet of Things to meet the needs of equipment manufacturers for remote operation and maintenance management of equipment.

2.3 Mobile APP / Mobile Cloud Assistant

Mobile APP / Mobile Cloud Assistant

3、Data Center

Used for data display, monitoring and data analysis. You can use MacMetter standard software, or you can develop your own monitoring platform to achieve remote monitoring, device management, data analysis and other functions.

4、Management System

The MES system can accurately collect and feed back production process information to track production process management. The ERP system provides a management platform for enterprises to make decision-making operations. The SCADA system is an automation system that realizes production process control and scheduling.
