Introduction

Cast film has excellent heat sealing performance and excellent transparency. It is one of the main packaging composite substrates. It is used to produce high-temperature cooking films and vacuum aluminum-plated films. With the increasing demand of the domestic cast film market, advanced cast film machines also have a broad market, and automated cast film production lines have bright prospects.

The cast film extruder processes raw material particles or powder into cast film products through the processes of heating raw materials, squeezing raw material slurry, pressing and cooling, winding and packaging.



Control Requirements

  • Control of the amount of different raw materials added

  • Die head heating temperature monitoring and adjustment

  • Synchronization of traction roller, cooling roller and embossing roller

  • Winding tension feedback and adjustment

  • According to the length of winding, cutting and changing control



Control scheme

    Because the production line is relatively long (through three rooms), this system separately controls the heating part and the transmission part. The heating part independently controls the heating through the local touch screen, and the transmission part performs single-action and linkage operation through the local touch screen.

     At the same time, in the central control room, the entire casting film control system is operated through the configuration software ViewPanel of McMitt. The heating, transmission and central control room use Ethernet to communicate.

     Transmission system: PLC controls the inverter, adjusts the speed of the feeding motor, and realizes the control of the amount of raw material added. Adjust the rotation speed to keep the traction roller, cooling roller and embossing roller synchronized.

     Heating system: control the temperature of overall feeding and extrusion through the MTC temperature control module. MTC comes with PID control, which can control the temperature of 50 channels accurately and conveniently.
